Vendor: LightGraphix

LD44X Uplight

SKU: LD44X-C1-350-LW27-NB-L-NGS-316SS-SC

The LD44X is a compact, high-performance uplight designed for both interior and exterior applications. Based on the proven LD42 and LD43 platforms, it features a 2-core sheathed cable for outdoor use and delivers up to 180 lumens at 700mA.

Regular price £107.28 Sale price £107.28

VAT included and shipping calculated at checkout

You can't add more LD44X Uplight in Default Title to cart

Usually ships within 4 weeks

Built To Order Item, we are unable to accept returns unless they are found to be faulty.

The LD44X is a compact, high-performance uplight designed for both interior and exterior applications. Based on the proven LD42 and LD43 platforms, it features a 2-core sheathed cable for outdoor use and delivers up to 180 lumens at 700mA. The LED and optics are recessed 10mm into the fitting for effective glare control, with optional aperture reductions of 45% or 70%, and an available 20° tilt film to focus light onto the lit surface for a more defined effect.

Built to withstand harsh environments, the LD44X includes a replaceable light engine and an integral anti-wicking barrier to protect against moisture ingress. Constructed from a hard anodised aluminium body with a precision-machined 316 stainless steel bezel, it’s suitable for recessed uplighting, wall washing, step lighting, and pathway applications. Rated IP68 and CB Certified, it is supplied with spring clips, or a fixing sleeve and O-rings for secure installation in even the most demanding environments.

Overall Diameter: 64mm Ø

Depth: 63mm

Cut Out: 57mm Ø

Tilt Angle (°): -

Rotation Angle (°): -

Light Source: LED

Wattage: 4.4W @ 350mA / 5.8W @ 500mA / 8.3W @ 700mA

Lumens: 574lm / 740lm / 949lm

Kelvin: 2200K / 2700K / 3000K

CRI: 93+

Beam Degree: 12° / 31° / 48°

Driver Required: Yes - Remote mounted 350mA

Switched: -

Dimmable: Yes

Dimming Type: Driver Dependent

Voltage: 2.6V

IP rating: IP66

Fire rated: -

The LD44X is a compact, high-performance uplight designed for both interior and exterior applications. Based on the proven LD42 and LD43 platforms, it features a 2-core sheathed cable for outdoor use and delivers up to 180 lumens at 700mA. The LED and optics are recessed 10mm into the fitting for effective glare control, with optional aperture reductions of 45% or 70%, and an available 20° tilt film to focus light onto the lit surface for a more defined effect.

Built to withstand harsh environments, the LD44X includes a replaceable light engine and an integral anti-wicking barrier to protect against moisture ingress. Constructed from a hard anodised aluminium body with a precision-machined 316 stainless steel bezel, it’s suitable for recessed uplighting, wall washing, step lighting, and pathway applications. Rated IP68 and CB Certified, it is supplied with spring clips, or a fixing sleeve and O-rings for secure installation in even the most demanding environments.

Overall Diameter: 64mm Ø

Depth: 63mm

Cut Out: 57mm Ø

Tilt Angle (°): -

Rotation Angle (°): -

Light Source: LED

Wattage: 4.4W @ 350mA / 5.8W @ 500mA / 8.3W @ 700mA

Lumens: 574lm / 740lm / 949lm

Kelvin: 2200K / 2700K / 3000K

CRI: 93+

Beam Degree: 12° / 31° / 48°

Driver Required: Yes - Remote mounted 350mA

Switched: -

Dimmable: Yes

Dimming Type: Driver Dependent

Voltage: 2.6V

IP rating: IP66

Fire rated: -
