Eco 10 High Density Led Strip

The Eco 10 High Density LED Strip by 100% Light UK is a 24V, 10W per metre linear lighting solution designed to deliver smooth, high-quality illumination across architectural and joinery applications. Featuring 280 high-efficiency LEDs per metre on a durable 2oz PCB, it offers exceptional CRI 97+ colour rendering with outputs ranging from 890 to 1090 lumens per metre, depending on the selected colour temperature. Available in 2200K, 2700K, 3000K and 4000K, it provides excellent flexibility for warm, ambient and more neutral lighting schemes. Available in IP20 or IP65, the Eco 10 High Density LED Strip supports runs of up to 12 metres and can be cut every 25mm, allowing accurate installation within bespoke details. The strip measures 10mm wide in IP20 and 12mm wide in IP65, with 3M 300LSE self-adhesive backing for straightforward mounting. When combined with an aluminium profile and opal diffuser with a minimum depth of 7mm, it can create a continuous, dot-free linear lighting effect.

Colour Temperature: 2700K

2700K
3000K

IP Rating: IP20

IP20
IP65

Product variants

Usually ships within 2-3 working days

General Information

The Eco 10 High Density LED Strip by 100% Light UK is a 24V, 10W per metre linear lighting solution designed to deliver smooth, high-quality illumination across architectural and joinery applications. Featuring 280 high-efficiency LEDs per metre on a durable 2oz PCB, it offers exceptional CRI 97+ colour rendering with outputs ranging from 890 to 1090 lumens per metre, depending on the selected colour temperature. Available in 2200K, 2700K, 3000K and 4000K, it provides excellent flexibility for warm, ambient and more neutral lighting schemes.

Available in IP20 or IP65, the Eco 10 High Density LED Strip supports runs of up to 12 metres and can be cut every 25mm, allowing accurate installation within bespoke details. The strip measures 10mm wide in IP20 and 12mm wide in IP65, with 3M 300LSE self-adhesive backing for straightforward mounting. When combined with an aluminium profile and opal diffuser with a minimum depth of 7mm, it can create a continuous, dot-free linear lighting effect.

Strip Width: 10mm / 12mm

Cut Point Interval: 25mm

Reel Length: 5m / 10m

Maximum Continuous Run: 12m

Mounting Method: Adhesive

Light Source: Integrated LED

LED Pitch (LEDs per Metre): 240

Lumen Output per Metre: 780lm/m / 820lm/m / 900lm/m

Colour Temperature: 2700K / 3000K / 4000K

CRI (Ra): 92

Colour Consistency (SDCM / MacAdam): 3 Step

Driver Type: Constant Voltage

Output Voltage: 24V

Power Consumption per Metre: 10W/m

Driver Required: Yes

Driver Included: No

Driver Location & Access: Remote mounted

Dimmable: Yes

Dimming Protocol: Mains dim (trailing edge) / DALI / 0-10V

Cable Entry / Connector Type: 200mm tails

IP Rating: IP20 / IP65

Warranty: 3 years
