Vendor: LightGraphix

LD10236 Wall Light

SKU: LD10236-

The LD10236 Wall Light is a powerful surface-mounted fitting designed to deliver low-glare up-and-down wall washing. Featuring twin recessed LED sources, multiple engine options and colour temperatures from 2200K to 5000K, it offers exceptional flexibility for architectural schemes. With IP67 protection, discreet fixing and a wide choice of finishes, it is ideal for premium interior and exterior projects.

Regular price £382.64 Sale price £382.64

Tax included and shipping calculated at checkout

You can't add more LD10236 Wall Light in Default Title to cart

Usually ships within 4 weeks

Built To Order Item, we are unable to accept returns unless they are found to be faulty.

The LD10236 Wall Light is a powerful double-output surface-mounted fitting designed to create a balanced up-and-down wall wash for both interior and exterior architectural applications. Two recessed LED sources sit within a matt black inner baffle and are secured with anti-glare rings, helping to reduce direct view of the light source while producing controlled illumination above and below the fitting. Its compact, minimal form is machined from a solid billet of aluminium, allowing the LD10236 to blend discreetly into contemporary façades, feature walls and premium architectural schemes.

Available with E3, E3-2CH, F1, Tunable White, RGBW and CLR LED engines, the LD10236 Wall Light offers extensive flexibility across colour temperatures from 2200K to 5000K, multiple beam angles and a wide range of paint finishes. Rated IP67, it is engineered for demanding exterior environments, while a stainless steel first-fix bracket and discreet M6 security grub screws provide a clean and robust installation. With double-ended output, strong thermal performance and numerous specification options, the LD10236 is a versatile choice for luxury residential, hospitality and commercial wall-washing applications.

Height: 150mm

Width: 71mm

Depth: 85mm

Tilt Angle (°): -

Rotation Angle (°): -

Light Source: LED

Wattage: 8.4W @ 350mA / 12 W @ 500mA

Lumens: 758lm / 986lm

Kelvin: 2200K / 2700K / 3000K

CRI: 93+

Beam Degree: 12°/ 19° / 34° / 54° / 15° x 49°

Driver Required: Yes - Remote mounted

Switched: -

Dimmable: Yes

Dimming Type: Driver Dependent

Voltage: 28V

IP rating: IP67

Fire rated: -

The LD10236 Wall Light is a powerful double-output surface-mounted fitting designed to create a balanced up-and-down wall wash for both interior and exterior architectural applications. Two recessed LED sources sit within a matt black inner baffle and are secured with anti-glare rings, helping to reduce direct view of the light source while producing controlled illumination above and below the fitting. Its compact, minimal form is machined from a solid billet of aluminium, allowing the LD10236 to blend discreetly into contemporary façades, feature walls and premium architectural schemes.

Available with E3, E3-2CH, F1, Tunable White, RGBW and CLR LED engines, the LD10236 Wall Light offers extensive flexibility across colour temperatures from 2200K to 5000K, multiple beam angles and a wide range of paint finishes. Rated IP67, it is engineered for demanding exterior environments, while a stainless steel first-fix bracket and discreet M6 security grub screws provide a clean and robust installation. With double-ended output, strong thermal performance and numerous specification options, the LD10236 is a versatile choice for luxury residential, hospitality and commercial wall-washing applications.

Height: 150mm

Width: 71mm

Depth: 85mm

Tilt Angle (°): -

Rotation Angle (°): -

Light Source: LED

Wattage: 8.4W @ 350mA / 12 W @ 500mA

Lumens: 758lm / 986lm

Kelvin: 2200K / 2700K / 3000K

CRI: 93+

Beam Degree: 12°/ 19° / 34° / 54° / 15° x 49°

Driver Required: Yes - Remote mounted

Switched: -

Dimmable: Yes

Dimming Type: Driver Dependent

Voltage: 28V

IP rating: IP67

Fire rated: -
